TLV803SDBZR IC SUPERVISOR 1 CHANNEL SOT23-3 Texas Instruments

Name: TLV803SDBZR IC SUPERVISOR 1 CHANNEL SOT233 Texas Instruments
Brand: Texas Instruments
Price: 1 USD

Brand Name : Texas Instruments

Model Number : TLV803SDBZR

MOQ : 1

Price : Based on current price

Payment Terms : T/T

Supply Ability : In stock

Delivery Time : 3-5 work days

Packaging Details : anti-static bag & cardboard box

Type : Simple Reset/Power-On Reset

Number of Voltages Monitored : 1

Voltage - Threshold : 2.93V

Output : Open Drain or Open Collector

Reset : Active Low

Reset Timeout : 120ms Minimum

Operating Temperature : -40°C ~ 125°C (TA)

Mounting Type : Surface Mount

Package / Case : TO-236-3, SC-59, SOT-23-3

Supplier Device Package : SOT-23-3

Contact Now

Product Details

Description: The TLV803SDBZR Texas Instruments Integrated Circuits (ICs) Supervisors is a surface mount SOT-23-3 package with a Digi-ReelR Alternate Packaging. It has a unit weight of 0.050717 oz and a maximum operating temperature of +125°C. It has a threshold voltage of 2.5V, 3V, 3.3V, and 5V, and a supply voltage max of 6V. It has an active-low reset type and a push-pull output type. It is lead-free and RoHS compliant.

Applications of the TLV803SDBZR Texas Instruments Integrated Circuits (ICs) Supervisors include power supply monitoring, system reset, and system initialization.

Features of the TLV803SDBZR Texas Instruments Integrated Circuits (ICs) Supervisors include a low supply current, a low reset threshold voltage, a low reset active-low output, and a push-pull output. It also has a wide operating temperature range of -40°C to +125°C and is RoHS compliant.

Specifications

Attribute	Attribute Value
Manufacturer	Texas Instruments
Product Category	Supervisors
Series	TLV803S
Type	Simple Reset/Power-On Reset
Packaging	Alternate Packaging
Unit-Weight	0.050717 oz
Mounting-Style	SMD/SMT
Package-Case	TO-236-3, SC-59, SOT-23-3
Operating-Temperature	-40°C ~ 125°C (TA)
Mounting-Type	Surface Mount
Output-Type	Active Low Open Drain
Supplier-Device-Package	SOT-23-3
Output	Open Drain or Open Collector
Reset	Active Low
Voltage monitoring relays	1
Reset-Timeout	120 ms Minimum
Voltage-Threshold	2.93V
Maximum Operating Temperature	+ 125 C
Operating-Supply-Current	20 uA
Battery-Backup-Switching	No Backup
Software Development Kit	TLV803SEVM-019
Supply-Voltage-Max	6 V
Supply-Voltage-Min	1.1 V
Package-Case	SOT-23-3
Watchdog-Timers	No Watchdog
Threshold-Voltage	2.5 V 3 V 3.3 V 5 V
Input Monitoring	4 Input
Manual-Reset	Manual Reset

Functional compatible component

Form,Package,Functional compatible component

Manufacturer Part#	Description	Manufacturer	Compare
TLV803SDBZT Power Circuits	3-pin voltage supervisor (reset IC) with active-low and open-drain reset 3-SOT-23 -40 to 125	Texas Instruments	TLV803SDBZR vs TLV803SDBZT

Descriptions

Supervisor Open Drain or Open Collector 1 Channel SOT-23-3

Processor Supervisor 2.93V 1 Active Low/Open Drain 3-Pin SOT-23 T/R

Supervisory Circuits 3P Vltg Supervisor
