MR2A16ACYS35 IC RAM 4MBIT PARALLEL 44TSOP2 Everspin Technologies Inc.

Product Categories
Sanhuang electronics (Hong Kong) Co., Limited
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

MR2A16ACYS35 IC RAM 4MBIT PARALLEL 44TSOP2 Everspin Technologies Inc.

Brand Name : Everspin Technologies Inc.

Model Number : MR2A16ACYS35

MOQ : 1

Price : Based on current price

Payment Terms : T/T

Supply Ability : In stock

Delivery Time : 3-5 work days

Packaging Details : anti-static bag & cardboard box

Memory Type : Non-Volatile

Memory Format : RAM

Technology : MRAM (Magnetoresistive RAM)

Memory Size : 4Mbit

Memory Organization : 256K x 16

Memory Interface : Parallel

Clock Frequency : -

Write Cycle Time - Word, Page : 35ns

Access Time : 35 ns

Voltage - Supply : 3V ~ 3.6V

Operating Temperature : -40°C ~ 85°C (TA)

Mounting Type : Surface Mount

Package / Case : 44-TSOP (0.400", 10.16mm Width)

Supplier Device Package : 44-TSOP2

Contact Now

Product Details

Introduction

Intended Functionality
The blood pressure monitor (BPM) reference design shows how to implement a system that can measure arterial blood pressure values. The system demonstrates control, data retention, analog acquisition, and connectivity functions, as well as the ability to interface with a user. These are achieved by using several Freescale devices.

Solution Benefits
The BPM reference design elements can be referenced for later development as:
• USB communication using the MC9S08JM60 as a bridge
• 2.4 GHz communication using the MC13202 ZigBee transceiver
• MRAM communications
• Use of MRAM to store user data
• MRAM driver to access MRAM memory
• User display using an OLED display
• User interface using the MPR083 proximity sensor
• Audio feedback using two timer pulse-width modulator (TPM) modules

Specifications

Attribute Attribute Value
Manufacturer Everspin
Product Category Memory ICs
Series MR2A16A
Packaging Tray Alternate Packaging
Mounting-Style SMD/SMT
Package-Case 44-TSOP (0.400", 10.16mm Width)
Operating-Temperature -40°C ~ 85°C (TA)
Interface Parallel
Voltage-Supply 3 V ~ 3.6 V
Supplier-Device-Package 44-TSOP2 (10.2x18.4)
Memory Capacity 4M (256K x 16)
Memory-Type MRAM (Magnetoresistive RAM)
Speed 35ns
Access-Time 35 ns
Format-Memory RAM
Maximum Operating Temperature + 85 C
Operating temperature range - 40 C
Operating-Supply-Current 105 mA
Interface-Type Parallel
Organization 256 k x 16
Data-Bus-Width 16 bit
Supply-Voltage-Max 3.6 V
Supply-Voltage-Min 3 V
Package-Case TSOP-44

Functional compatible component

Form,Package,Functional compatible component

Manufacturer Part# Description Manufacturer Compare
MR2A16AVYS35
Memory		 Memory Circuit, 256KX16, CMOS, PDSO44, 0.400 INCH, ROHS COMPLIANT, PLASTIC, TSOP2-44 Everspin Technologies MR2A16ACYS35 vs MR2A16AVYS35
MR1A16AVYS35
Memory		 Memory Circuit, 128KX16, CMOS, PDSO44, 0.400 INCH, ROHS COMPLIANT, PLASTIC, TSOP2-44 Everspin Technologies MR2A16ACYS35 vs MR1A16AVYS35
MR2A16AYS35R
Memory		 Memory Circuit, 256KX16, CMOS, PDSO44, 0.400 INCH, ROHS COMPLIANT, PLASTIC, TSOP2-44 Everspin Technologies MR2A16ACYS35 vs MR2A16AYS35R
MR1A16AVYS35R
Memory		 Memory Circuit, 128KX16, CMOS, PDSO44, 0.400 INCH, ROHS COMPLIANT, PLASTIC, TSOP2-44 Everspin Technologies MR2A16ACYS35 vs MR1A16AVYS35R
MR1A16AYS35
Memory		 Memory Circuit, 128KX16, CMOS, PDSO44, 0.400 INCH, ROHS COMPLIANT, PLASTIC, TSOP2-44 Everspin Technologies MR2A16ACYS35 vs MR1A16AYS35
MR2A16AYS35
Memory		 Memory Circuit, 256KX16, CMOS, PDSO44, 0.400 INCH, ROHS COMPLIANT, PLASTIC, TSOP2-44 Everspin Technologies MR2A16ACYS35 vs MR2A16AYS35
MR2A16ACYS35R
Memory		 Memory Circuit, 256KX16, CMOS, PDSO44, 0.400 INCH, ROHS COMPLIANT, PLASTIC, TSOP2-44 Everspin Technologies MR2A16ACYS35 vs MR2A16ACYS35R
MR2A16AVYS35R
Memory		 Memory Circuit, 256KX16, CMOS, PDSO44, 0.400 INCH, ROHS COMPLIANT, PLASTIC, TSOP2-44 Everspin Technologies MR2A16ACYS35 vs MR2A16AVYS35R
MR1A16ACYS35R
Memory		 Memory Circuit, 128KX16, CMOS, PDSO44, 0.400 INCH, ROHS COMPLIANT, PLASTIC, TSOP2-44 Everspin Technologies MR2A16ACYS35 vs MR1A16ACYS35R

Descriptions

MRAM (Magnetoresistive RAM) Memory IC 4Mb (256K x 16) Parallel 35ns 44-TSOP2
MRAM 4Mbit Parallel 3.3V 44-Pin TSOP-II Tray
NVRAM 4Mb 3.3V 35ns 256Kx16 Prallel MRAM
