ADP1715ARMZ-R7 IC REG LIN POS ADJ 500MA 8MSOP Analog Devices Inc.

Name: ADP1715ARMZR7 IC REG LIN POS ADJ 500MA 8MSOP Analog Devices Inc
Brand: Analog Devices Inc.
Price: 1 USD

Brand Name : Analog Devices Inc.

Model Number : ADP1715ARMZ-R7

MOQ : 1

Price : Based on current price

Payment Terms : T/T

Supply Ability : In stock

Delivery Time : 3-5 work days

Packaging Details : anti-static bag & cardboard box

Output Configuration : Positive

Output Type : Adjustable

Number of Regulators : 1

Voltage - Input (Max) : 5.5V

Voltage - Output (Min/Fixed) : 0.8V

Voltage - Output (Max) : 5V

Voltage Dropout (Max) : 0.4V @ 500mA

Current - Output : 500mA

Current - Quiescent (Iq) : 100 µA

Current - Supply (Max) : 650 µA

PSRR : 67dB ~ 53dB (1kHz)

Control Features : Enable, Soft Start

Protection Features : Over Current, Over Temperature

Operating Temperature : -40°C ~ 125°C (TJ)

Mounting Type : Surface Mount

Package / Case : 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)

Supplier Device Package : 8-MSOP

Contact Now

Product Details

GENERAL DESCRIPTION

The ADP170/ADP171 are low voltage input, low quiescent current, low-dropout (LDO) linear regulators that operate from 1.6 V to 3.6 V and provide up to 300 mA of output current. The low 66 mV dropout voltage at 300 mA load improves efficiency and allows operation over a wide input voltage range. The low 23 µA of quiescent current at a 0 mA load makes the ADP170/ADP171 ideal for battery-operated portable equipment.

FEATURES

Maximum output current: 300 mA
Input voltage range: 1.6 V to 3.6 V
Low quiescent current IGND = 23 µA with 0 mA load IGND = 170 µA with 300 mA load
Low shutdown current: <1 µA
Low dropout voltage: 66 mV at 300 mA load
Output voltage accuracy: ±1%
Up to 31 fixed-output voltage options available from 0.8 V to 3.0 V
Adjustable-output voltage range 0.8 V to 3.0 V (ADP171)
Accuracy over line, load, and temperature: ±3%
Stable with small 1 µF ceramic output capacitor
PSRR performance of 70 dB at 10 kHz and 73 dB at 1 kHz
Low noise: 30 µV rms at VOUT = 0.8 V
Current limit and thermal overload protection
Logic-controlled enable
Compact 5-lead TSOT package

APPLICATIONS

Mobile phones
Digital camera and audio devices
Portable and battery-powered equipment
DSP/FPGA/microprocessor supplies
Post dc-dc regulation

Specifications

Attribute	Attribute Value
Manufacturer	Analog Devices
Product Category	Linear Voltage Regulators
Series	ADP1715
Packaging	Alternate Packaging
Unit-Weight	0.004938 oz
Mounting-Style	SMD/SMT
Package-Case	8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
Operating-Temperature	-40°C ~ 125°C
Mounting-Type	Surface Mount
Supplier-Device-Package	8-MSOP
Voltage-Input	2.5 V ~ 5.5 V
Current-Output	500mA
Voltage-Output	0.8 V ~ 5 V
Regulator-Topology	Positive Adjustable
Voltage-Dropout-Typical	0.32V @ 500mA
Number-of-Regulators	1 Regulator
Current-Limit-Min	550mA
Maximum Operating Temperature	+ 125 C
Operating temperature range	- 40 C
Input-Voltage-MAX	5.5 V
Output-Current	500 mA
Input-Voltage-MIN	2.5 V
Load-Regulation	15 uV
Package-Case	MSOP-8

Descriptions

Linear Voltage Regulator IC Positive Adjustable 1 Output 0.8 V ~ 5 V 500mA 8-MSOP

LDO Regulator Pos 0.8V to 5V 0.5A 8-Pin MSOP T/R

LDO Voltage Regulators IC 500mA LDO CMOS w/ Soft Start
